Specifications

• Dimensions

  add remove
  • Length:
    2370 mm
  • Seat height, unladen:
    675 mm
  • Ground clearance:
    115 mm
  • Trail:
    104 mm
  • Wheelbase:
    1665 mm
  • Tyres, front specifications:
    160/60R18,70V,BW
  • Tyres, rear specifications:
    240/40R18,79V,BW
  • Fuel capacity:
    18.9 l
  • Oil capacity:
    4.7 l
  • Weight, as shipped:
    304 kg
  • Weight, in running order:
    317.06 kg
• Engine

  add remove
  • Engine:
    Milwaukee-Eight™ 114
  • Bore:
    102 mm
  • Stroke:
    114.3 mm
  • Displacement:
    1868 cm³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-2 staggered; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    161 Nm
  • Engine torque (RPM):
    3000
  • Lean angle, right (deg.):
    25.6
  • Lean angle, left (deg.):
    25.6
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    43 mpg (5 l/100km)
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Wheels, front type:
    Machined, Lakester cast aluminum
  • Wheels, rear type:
    Machined, Lakester cast aluminum
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS (if equipped), security, low battery voltage, low fuel
  • Gauges:
    5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
